Processor and Performance
• Chipset: Qualcomm Snapdragon 8 Elite Gen 5 Mobile Platform
• CPU: 3rd Generation Oryon CPU, up to 4.6GHz
• GPU: Adreno GPU
• Manufacturing Process: TSMC 3rd Generation 3nm Process
• AI Engine: Qualcomm AI Engine
• AI Display Chip: D2 with Super Resolution, Frame Insertion, and HDR Enhancement
• Cooling System: 6700mm² 3D vapor chamber cooling
Memory and Storage
• RAM: 12GB / 16GB LPDDR5x
• Storage: 256GB / 512GB / 1TB UFS 4.1
• Maximum Configuration: 16GB + 1TB
Body and Design
• Colors: Denim Blue, Flowing Gold, White, Black
• Dimensions: 163.33 × 77.82 × 7.9 mm (Denim 8.3 mm)
• Weight: 218 g (Denim 220 g)
• Frame: Aluminum Alloy
• Protection: Xiaomi Longjing Glass
• Water/Dust Resistance: IP68
Display
• Type: OLED Flat Display
• Size: 6.9 inches
• Resolution: 2608 × 1200 (1.5K Super Pixel)
• Color Depth: 12-bit (68.7 billion colors)
• Refresh Rate: Up to 120Hz
• Touch Sampling Rate: Up to 480Hz
• Brightness: Peak 3500 nits, Minimum 1 nit
• Color Gamut: DCI-P3 Wide Color
• Features: Full RGB pixel arrangement, HDR10+, HDR Vivid, Dolby Vision, TrueColor calibration
• Glass: Xiaomi Longjing cover glass
• Other Features: DC dimming, 3D ultrasonic fingerprint sensor, wet-hand touch support
Battery and Charging
• Battery Capacity: 7560mAh (typical) / 7420mAh (rated)
• Battery Type: Built-in lithium polymer
• Charging Chip: Xiaomi Surge P3
• Battery Management Chip: Xiaomi Surge G2
• Wired Charging: 100W fast charging (USB Type-C, GaN adapter included)
• Wireless Charging: 50W wireless fast charging
• Reverse Charging: 22.5W wired/wireless
• Charging Protocols: QC2.0 / QC3.0 / QC3+ / PD2.0 / PD3.0
Main Camera System (Rear)
• Primary Camera: 50MP Light Hunter™ 950, 1/1.31” sensor, OIS, 13.5EV dynamic range, 4-in-1 2.4μm fusion pixels, 1G+6P lens
• Telephoto Lens: 50MP 5x Periscope, ƒ/3.0 aperture, 5x optical zoom, 10x lossless zoom, OIS
• Ultra-Wide Lens: 50MP, ƒ/2.4 aperture, 102° field of view
• Video Recording:
• 8K @30fps
• 4K @30/60fps
• 1080p @30/60fps
• 720p @30fps
• Slow Motion:
• 720p @120/240/480/960/1920fps
• 1080p @120/240/960fps
• Photography Modes: Night mode, Panorama, Pro, HDR10+, Portrait, Long Exposure, Timelapse, Super Macro, Film Filters, AI Beautify, Voice Control, Watermark, Super Stabilization
Front Camera
• Resolution: 32MP
• Features: Portrait, Beauty mode, Filters, HDR, Timelapse, Gesture capture, Voice capture
• Video Recording:
• 4K @30fps
• 1080p @30/60fps
• 720p @30fps
• Slow Motion: 720p @120fps
Network and Connectivity
• SIM: Dual Nano-SIM
• 5G Bands: n1 / n3 / n5 / n7 / n8 / n18 / n26 / n28 / n38 / n40 / n41 / n48 / n66 / n77 / n78 / n80 / n81 / n83 / n84 / n89
• 4G Bands (FDD-LTE): B1 / B3 / B4 / B5 / B7 / B8 / B18 / B19 / B26 / B28 / B66
• 4G Bands (TDD-LTE): B34 / B38 / B39 / B40 / B41 / B42 / B48
• 3G Bands (WCDMA): B1 / B4 / B5 / B6 / B8 / B19
• 2G Bands (GSM): B3 / B5 / B8
• MIMO: 4x4 MIMO antenna support
• SIM Function: Dual 5G standby, dual VoLTE HD voice
• Wi-Fi: Wi-Fi 7 / Wi-Fi 6 / Wi-Fi 5 / Wi-Fi 4 / 802.11a/b/g
• Wi-Fi Features: 2.4GHz & 5GHz dual-band, Wi-Fi Direct, Miracast, 2x2 MIMO
• Bluetooth: Version 5.4, supports AAC / LDAC / LHDC 5.0 / LC3 / ASHA / Auracast / MIHC
• Navigation: GPS (L1+L5), GLONASS (G1), Galileo (E1+E5a), Beidou (B1I+B1C+B2a), QZSS (L1+L5), NavIC, A-GNSS, Wi-Fi positioning
• NFC: Supports Mi Pay, transit cards, door keys, and digital car keys
Audio
• Speaker System: 2.1-channel stereo triple speaker setup
• Independent Subwoofer: Included
• Certifications: Hi-Res Audio, Hi-Res Audio Wireless, Dolby Atmos, QQ Music Premium Certification
• Audio Formats: MP3, FLAC, APE, AAC, OGG, WAV, AMR, AWB
• Video Formats: MP4, MKV, WEBM, 3GP, MOV
• Video Playback: HDR10/10+, HLG
Sensors
• Proximity Sensor
• 360° Ambient Light Sensor
• Accelerometer
• Color Temperature Sensor
• Electronic Compass
• Gyroscope
• Infrared Remote Sensor
• Flicker Sensor
• X-Axis Linear Motor
Operating System
• OS: Xiaomi HyperOS 3
In the Box
• Redmi K90 Pro Max Smartphone
• 100W Power Adapter
• USB Type-C Cable
• Protective Case
• SIM Ejector Tool
• User Manual with Warranty Card
• Pre-applied Screen Protector
